Page 75
Section 5 - 1
HYDRO 15 (Service Manual) 10/06
© 2006
Alamo Industrial
HYDRO 15
Hydraluic Cylinder
Service and Repair
Section 5
HYDRAULIC SCHEMATICS
1 - WING LIFT & FOLD CYLINDERS
2 - STANDARD AXLE LIFT CYLINDER
3 - OPTIONAL AXLE LEVEL LIFT CYLINDERS
This section contains the procedures to service and/or re-
pair the mower wing lift cylinders, standard axle lift cylinder
and the optional axle level lift cylinders. Review the cylinder
schematics to determine which axle lift system was installed
on the mower. The 15 foot Model and the 10 foot model are
the same with the exception only one wing is used on the 10
foot model.
