Speed Increaser Service & Repair
Speed Increaser (1:4 Increase)
(See Figure 4)
Item
Qty
Description
1
1
Splined Shaft Adapter w/ Snap Ring Groove (use w/ item 3)
1A
1
Splined Shaft Adapter w/o Snap Ring Groove (use w/ item 3A)
2
1
Pinion Gear, High Speed 18 Tooth
3
1
External Snap Ring (use w/ item 1)
3A
1
Splined Shaft Adapter Spacer (use w/ item 1A)
5
1
Shaft & Gear, Low Speed 72 Tooth
6
1
Pump Flange
7
1
Cover, Closed
9
2
Cover, Open
10
3
Seal
11
1
Spacer Ring
12
1
Breather Plug
13
1
Bearing Cup
14
1
Bearing Cone
15
1
Housing Half, Non Breather Side
16
1
Housing Half, Breather Side
17
2
Dowel Pin, Upper or Lower
18
1
Gasket, F/ Housing Halves
19
3
Bearing Cup
20
3
Bearing Cone
21
AR
Shim, Aluminum .005
22
AR
Shim, Aluminum .007
23
AR
Shim, Aluminum .020
24
3
Shim, Fibre .005
25
AR
Shim, Aluminum .005
26
AR
Shim, Fibre .005
27
1
Shim, Aluminum .007
28
AR
Shim, Aluminum .020
29
24
Bolt, Allen Head 5/16"-NC X 3-1/4" Gr 5
30
24
Lockwasher, 5/16"
31
8
Bolt, Hex Head 3/8"-NC X 3-1/4" Gr 5
32
8
Nut, 3/8" NC
33
8
Lockwasher, 3/8"
34
8
Pipe Plug (1 plug is removed to install Breather)
35
2
Spacer Ring
