Chapter 3 Getting Started
3-19
Chapter 3 Getting Started
1
Press {ACCESS} for the desired Channel.
2
At the Input Channel & Inserts panel, press either
{MIC} or {LINE} as required, and set the input GAIN
knob to a suitable setting.
3
Make sure {CHANS} is selected on the Select To
Faders panel (fire-up default).
4
At the Routing panel, select { L } and { R } (fire-up
default) if not already lit.
5
Adjust the level to the Main Output Bus with the
Channel Fader.
6
Open the Main Fader and turn up the CR Monitor
level.
3-10-1 To Route a Mic or Line Input to the Main Output Bus
1 3 4 5 6 2
