6-3 Central Section Panels
6-3-3 Control Keyboard Panel
CONTROL KEYBOARD
This panel contains the Control Keyboard dedicated to the Session
Management™ and system automation, along with 4 sets of Tape
Remotes.
Dedicated Keys
The majority of commands are implemented using the dedicated command
keys on this keyboard. The QWERTY keyboard, housed under a sliding
cover between the Trackerballs in the centre section, is used mainly to type
in specific names for Titles, Cues and Tracks, etc.
