A-14
Appendixes
Appendixes
Specifications
Full Channels Equaliser & Filters
Section Gain Frequency Q/Slope Overshoot
LF Filter -6dB Steps 20-500Hz 0 -36dB/Oct -
LF Peak/Shelf +/-20dB 20-400Hz 0.5 - 16 0 – 50% (Q adjust in ‘Shelf’)
LMF +/-20dB 30-600Hz 0.5 - 16 -
MF +/-20dB 100Hz-6kHz 0.5 - 16 -
HMF +/-20dB 600Hz-18kHz 0.5 - 16 -
HF Peak/Shelf +/-20dB 2-20kHz 0.5 - 16 0 – 50% (Q adjust in ‘Shelf’)
HF Filter -6dB Steps 1-20kHz 0 -36dB/Oct -
Return Channels & MAIN Outputs Equaliser
Section Gain Frequency Q/Slope Overshoot
LF Peak/Shelf +/-20dB 20-400Hz 0.5 - 16 0 – 50% (Q adjust in ‘Shelf’)
HF Peak/Shelf +/-20dB 2-20kHz 0.5 - 16 0 – 50% (Q adjust in ‘Shelf’)
Dynamics
Dynamics Gain Reduction:
All levels in the table below are referenced to full scale and time constants
apply to a 10dB gain change. The time constant marked * denotes a
calculated value for 10dB gain change since the true figure is 40dB gain
change in 20.8us (1 sample).
Full Channels Dynamics
Section Threshold Ratio/Range Attack Hold Release
Gate -80 - 0dB 0 - -80dB 5
µ
s* - 26ms 10ms - 10s 7.8 - 519ms
Expander -60 - 0dB 0 - -80dB 0.26 - 104ms 10ms - 20s 519us- 519ms
Compressor -60 - 0dB 1:1 - Limit 519
µ
s - 52ms 10ms - 30s 52ms - 3.1s
Limiter -60 - 0dB - 100
µ
s - 500ms 50ms - 30s 100ms - 10s
Gain Make-up Soft Curves
Compressor 0-24dB 5dB, 10dB, 15dB, 20dB across Threshold
