6-84
Chapter 6 Technical Descriptions
Chapter 6 Technical Descriptions
6-3 Central Section Panels
3 3 3 3 3 SET M/T STEMS Push-Button
Allows the format of the Multitrack Stems to be set: STEREO, LCRS, 5.1
or 7.1 using the { + } and { – } buttons either side of the 8 character dot
display, which indicates the current format. The {SET M/T STEMS}
function is locked unless {LOCK} has been pressed to unlock it first. It
inter-cancels with the {SET MAIN WIDTH} button.
With {SET M/T STEMS} set and {LOCK} lit, indicating lock status, the { + }
and { – } buttons can be used to step through Stems A-H, indicated by the
letter at the right in the 8 character display. Set-up settings relating to each
Stem will be displayed accordingly, in other sections of this panel.
4 4 4 4 4 + / – Push-Buttons (either side of character display)
Enable the appropriate format to be selected for the Main Output Bus and
Multitrack Stems, depending on whether {SET MAIN WIDTH} or
{SET M/T STEMS} is selected. {LOCK} must be pressed first to unlock the
set-up facility.
5 5 5 5 5 8 Character Display
Indicates the format selected STEREO, LCRS, 5.1 or 7.1 and stem, one of
A-H.
6 L, L/C, C, R/C, R, L-S, SUB and R-S Push-Buttons (each with
track number display)
These buttons, combined with the { + } and { – } push-buttons 7
7 7 7 7, allow
assignment of surround routing buttons, in the MULTI-FORMAT section
of the Routing panel, to the Multitrack Busses in order to set up Stems.
(The set-up procedure is described in detail in Chapter 4).
To make an assignment, unlock {LOCK}, then press and hold the desired
destination { L }, { L/C } etc. Step through the tracks with the { + } and { – }
buttons 7
7 7 7 7, until the desired track number is displayed in the two character
display. Release the destination button. Press {LOCK} to re-lock the set-up
or allow it to time out.
7 7 7 7 7 + / – Push-Buttons
Combined with the buttons described in 6, these buttons allow toggling
through the Multitrack routing bus numbers in order to set up Stems using
the Multitrack Busses.
8 8 8 8 8 9 9 9 9 9 Monitor Level Knob & 8 Character Display
Controls the overall level to the Control Room Monitor LS level when
{CAL} is not selected. This control operates in parallel with the Monitor
Level on the Monitor panel.
The 8 Character Dot Display indicates level setting in dB SPL including
calibrated settings. When {CAL} is selected, push and rotate to define a
new calibration setting. CAL MODE in the PREFS GUI must be set to
‘ON’ in order that the calibrated settings are active.
