Chapter 5

Control Screens

5-33

Chapter 5 Control Screens

PAN OUT RESET

• RESET

- Switching a Pan out will centre it if switched in again.

• RESTORE

- Switching a Pan out will centre it, but it will return to

its previous setting if switched in again.

ST METER

This option applies to the central stereo meter when

{MAIN} is selected

under the “METERS” heading at the top right of the Monitor panel.
• MAIN

- Central stereo meter displays the L and R signals from

the Main Output Bus.

• FDOWN

- Central stereo meter displays the L and R signals

derived in the Fold-Down Matrix.

LS3

This option applies to the stereo CR Monitor LS3, when

{MAIN} is selected

under the “MONITOR LS” heading at the middle right of the Monitor
panel.
• MAIN

- The LS3 feed is the L and R signals from the Main

Output Bus.

• FDOWN

- The LS3 feed is the L and R signals derived in the

Fold-Down Matrix.

OSC A & OSC B

Oscillators outputs A & B are controlled by clicking on

4 and $ to the

right of the parameter displays.
• Level: dBs

- -100, -90, -80, -70, -60, -50, -40, -30 – 0dB in 1dB

steps.

• Frequency: Hz - 20, 30, 40, 50, 60, 70, 80, 90, 100, 200, 300, 400, 500,

600, 700, 800, 900.

kHz - 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 14, 16, and 20.

The Softkeys for this GUI:

• TOP

- Selects the top level LOGO screen

• IO ALIAS

- Alias naming facility for all types of I/O

• DIALOG

- Naming facility for all I/O Scribble pop-ups

• FIO MONO

- Set-up facility for Fast Insert I/O

• SRC

- Sample Rate Converter control
