MADI Connections
MADI connections may be made directly to the SP Rack
without the need for I/O Racks.
Inputs
Outputs
Con. Type
Notes
MADI
56
56
2 BNC 75
Ω
Connect
(1 OPTICAL)
Directly to
SP Rack
Maximum I/O Configurations
Below are the maxima for each type of I/O module type per
system. It should be noted, however, that the total number of
audio connections, whether analogue or digital, should not
exceed:
The Maximum of 448 Inputs and 448 Outputs per System
I/O Type
Maximum
Maximum Number of Modules by Type
Analogue In
128
32 4-ADC Units, 16 8-ADC Units
Analogue Out
128
32 4-DAC Units, 16 8-DAC Units
AES/EBU In
56 Stereo
4 (Inputs & Outputs on same module)
AES/EBU Out
32 Stereo
4 (Inputs & Outputs on same module)
TC/9P/MIDI/Video
1
1
GPI In/Out
12
1 (Includes 48 Tracks of Dash Record Remotes)
MADI In/Out
112
2 Connections (Direct to SP Rack)
Each I/O Rack can have up to a maximum of 56 Audio Inputs
and Outputs, analogue or digital.
Dimensions & Weight
Equipment
Width
Height
Depth
Weight
24C24 Control Console
2516mm
1046mm
1215mm
382 kg
99.1”
41.2”
48”
842 lb 3 oz
24C0 Control Console
1620mm
1046mm
1215mm
221 kg
63.9”
41.2”
48”
487 lb 4 oz
Signal Processor Rack
480mm
670mm
600mm
60 kg
19”
26.5” (15U)
23.7”
132 lb 4 oz
Analogue Digital I/O Rack
480mm
315mm
455mm
25 kg
19”
12.5” (7U)
18.0”
55 lb 2 oz
