A-11 – Sony OXF-R3 User Manual
Page 381

Appendixes
A-11
Appendixes
4 Ch Analogue LINE Outputs
Output Type
• Electronic Floating type with performance identical,
balanced and unbalanced. Maximum output level +24dBm.
Equivalent Source Impedance
• 20Hz–20kHz < 10
Ω
Output Balance
• 20Hz–20kHz < 60dB (0.1%)
Minimum Destination Load
• 300
Ω
Frequency Response
• 48kHz Sample Rate 20Hz–20kHz, +/- 0.2dB
Output Noise
• < -109dBr
Distortion 20Hz–20kHz
• -1dBfs: < -96dBfs (0.005% THD+N)
• -50dBfs: < -135dBfs
Crosstalk Between Outputs
• 20Hz–20kHz < -100dBfs
Stability
• Unconditional
Compliance
• +/- 15V
Short Circuit Tolerance
• Indefinite in all modes
