5-2 Channel Screens
IMPORTANT
I/O Pop-up COLOUR CODING
The pop-ups which allow I/O assignments are colour coded as follows:
Text
• Black 4 Channel ADCs, DACs and AES I/O
• Yellow 8 Channel ADCs and DACs
Background colour of pop-up buttons
• Mauve/Blue I/O SP-LINK-0 - General Purpose
• Light Blue I/O SP-LINK-1 - General Purpose
• Light Blue I/O SP-LINK-2 - Multitrack Machines
• Dark Blue I/O SP-LINK-3 - Insert Device I/O
MADI Links in general
The OXF-R3 has up to 4 SP-LINK modules each with 2 MADI circuits,
allowing direct connection from the S/P Rack to remote I/O Racks and
Dash tape machines. Possible I/O assignments for each loop are as below.
The numbers of inputs and outputs vary according to system requirements,
product type and software variant. The following are maximums.
SP-LINK-1
General purpose for connections to inputs and outputs.
• Analogue Inputs : ADC-1 to ADC-200
• Analogue Outputs : DAC-1 to DAC-200
• Digital Inputs : AES-1 to AES-32 & AES-65 to AES-200
• Digital Outputs : AES-1 to AES-32, AES-65 TO AES-80
SP-LINK-2
I/O for connections to multitrack machines.
• MADI Inputs : MT1-1 to MT1-48 & MT2-1 to MT2-48
MD1-49 to MD1-56 & MD2-49 to MD2-56
• MADI Outputs : MT1-1 to MT1-48 & MT2-1 to MT2-48
SP-LINK-3
For connection specifically to Insert devices.
• Analogue Inputs : ADC-1 to ADC-200
• Analogue Outputs : DAC-1 to DAC-200
• Digital Inputs : AES-33 to AES-64 & AES-81 to AES-200
• Digital Outputs : AES-33 to AES-64
SP-LINK-0
General purpose for connections to inputs and outputs.
• Analogue Inputs : ADC-201 to ADC-312
• Analogue Outputs : DAC-201 to DAC-312
• Digital Inputs : AES-201 to AES-312
• Digital Outputs : None
