Chapter 6 Technical Descriptions
6-75
Chapter 6 Technical Descriptions
4 SOLO Push-Buttons
Allow grouped Solo function according to the groups set up. See 6 and
7 below.
5 CUT Push-Buttons
Allow grouped Cut function according to the groups set up. See 6 and 7
below.
6 SENDS Push-Buttons
Select the channel signal being sent to the M/T as monitor source. May be
linked to control SEND buttons on Pans panels as groups (see section
6-2-3); hold down this button (it will flash) then select SEND(s) on the
channels that are required to be grouped. Latching SENDS will set all
SEND buttons in the group.
7 RETS Push-Buttons
Select the return signal from the M/T. May be linked to control RET
buttons on Pans panels as groups (see section 6-2-3); hold down this
button (it will flash) then select RET(s) on the channels required to be
grouped. Latching RETS will set all RET buttons in the group.
Note:
1 Setting up a group with either SENDS or RETS will cause the group to
be set for channel SENDs, RETs, SOLOs and CUTs.
2 The grouping function is not operable in Multi-Format mode if any of
these buttons sets are assigned to control the monitor switching of a
Stem or number of Stems (see sections 4-13-4 and 4-13-5).
Using Keyboard Entry to Record Arm Channel Tracks
Press {RECORD} at the appropriate machine remotes in the master section.
Then use the QWERTY Keyboard: Specify Channels as Below {ENTER}
• Channels ranges are specified with ‘..’ as a separator:
1..32 = Channels 1-32
• Individual items are separated by ‘.’
2 . 4 . 25 = Channels 2, 4, and 25
• Unlimited strings are possible in the same entry:
e.g. 1 . 3 . 5 .. 08 . 12 .. 42 = Channels 1, 3, 5-8 and 12-42
Track arming using the keyboard is not additive and must be accomplished
using a single entry. In other words the latest entry overwrites the previous
one.
Press {RECORD} { 0 } {ENTER} to disarm all the tracks that are armed.
