6-26
Chapter 6
Technical Descriptions
Chapter 6 Technical Descriptions
6-2 Channels Section Panels
SOURCE section
3
8 Character Display
Indicates signal source point in channel chain from where the signal to
feed the Multitrack is derived.
+/- Push-buttons allow selection of the junction in channel path from
where the Multitrack signal is sourced. The signal will be taken directly
from the ouput of the function displayed.
Operable only if the IN button for the Multitrack (displayed as MULTI) is not
selected on the Input Channel & Inserts panel.
INSERT section
4
+/- Push-Buttons (Not operational in this version)
Allow the list of insertable devices to be displayed, one at a time, on the 8
character display.
5
INSERT IN Push-Button
Inserts the device selected via the I/O GUI (see Chapter 5).
It is not possible to change insert selection when the INSERT IN is selected.
Multitrack LEVEL and Pan section
6
LEVEL Knob
Controls the level of signal being sent to the M/T routing bus switching.
7
AFL Push-Button
Sends the signal post the M/T Level to monitor LS.
8
CUT Push-Button
Mutes the signal post M/T Level control.
9
PAN IN Push-Button
Switches in the Pan functionality according to format selected (Stereo or
Multi-Format selected in the centre section). For stereo panning, at least
one odd and one even track must be selected in the Multitrack routing
section.
0
L/R PAN Knob
Allows left/right panning.
Note:
Note:
