6-2-5 Input and Equaliser Panel
This panel is divided into two distinct sections, the INPUT CHANNEL &
INSERTS section and the EQUALISER & FILTERS section, designated
A and B respectively in the illustration.
A INPUT CHANNEL & INSERTS section
1 MIC Push-Button
Selects the MIC input amp as the source as assigned on the Mic Inputs
GUI.
2 M/T Push-button
Selects the digital or analogue M/T return input as assigned on the M/T
Return Inputs GUI.
INPUT CHANNEL & INSERTS and EQUALISER & FILTERS panel
