A-16
Appendixes
Appendixes
Specifications
I/O Rack Modules
Each I/O rack contains:
• 1 x Digital Link Card Module
• Up to 10 Device Card Modules such as ADCs, DACs etc.
I/O Module Inputs Outputs Con. Type Notes
Digital Link 1 MADI 1 MADI 2 BNC 75 Ω For Connection
(1 Optical) to SP Rack
RS422 General Purpose Port 1 9P-Dsub
RS232 Diagnostic Port 1 9P-Dsub
Analogue In 4 MIC, 4 Line 8 XLR-3-31 112 dB
(Mic & Line inputs cannot be Dynamic Range
used simultaneously)
Analogue In 8 MIC/Line 8 XLR-3-31 107 dB
Dynamic Range
Analogue Out 4 Line 4 XLR-3-32 110 dB
Dynamic Range
Analogue Out 8 Line 8 XLR-3-32 104 dB
Dynamic Range
AES/EBU In 4 Stereo 4 Stereo 4 XLR-3-31
AES/EBU Out 4 Stereo 4 Stereo 4 XLR-3-32
SDIF-2 (24) 24 Mono 24 Mono 2 50P-Dsub
TC In Timecode Timecode 1 XLR-3-31
MIDI In Out 3 5P-DIN 180 °
+ THRU CON.
Video Ref In 1 BNC 75 Ω
Multi Remote Control REC/RDY tally READY 1 100P
command
GPI OPTO In Relay 25P-Dsub Relay & Opto
(photo coupler) Closures 30V Max.
Relay 30mA
Max.
I/O Rack System
The I/O system for the OXF-R3 utilises a universal rack design to house
both analogue and digital I/O. It may, under certain circumstances, be
possible to mix analogue and digital I/O modules in the same rack
. Each
rack requires AC mains power.
