Chapter 3 Getting Started

Chapter 3

Getting Started

3-7

1 Meter Bridge – Mono Meters

2 Meter Bridge – Stereo Meters

3 Channel Screens (6)

4 Routing Panels

5 Multi-Channel Set-up Panel

6 Super Send Group Masters

7 Sends Masters

8 Central Control Screen

9 Sends Panels

0 Free Assign Area/Dynamics

Panels

! ¡ Input & Equaliser Panels

!™ Multitrack Panels

! £ Track Monitoring Controls

! ¢ Assignable Pan Knobs

!∞ Select to Pans Panels

! § Monitor & Foldback Panel

! ¶ Control Keyboard & Automation

Controls

! • Assignable Channel Faders

! ªSelect to Faders Panels

@º Multi-Purpose Faders

@¡ Main Output Fader

@

™

Trackerballs

@£ QWERTY Keyboard (beneath

sliding cover)

!ª

@™

!∞

!•

!£

!¢

!™

1

3

3

3

9

!º

4

!¡
