6-4 Meter Bridge
The standard meters used on the Meter Bridge of the OXF-R3 are a bargraph type utilising back-lit LCD
technology with digital scales.
6-4 Meter Bridge
6-4-1 Mono Channel Meters
Channel meters are fitted, one per channel fader, in blocks of eight. Each
meter block is situated directly above a channel’s LCD screen. This layout
enables channel related information, such as routing assignments which
are also displayed in blocks of eight, to line up with their associated
meters.
MONO Channel Meters block
