Chapter 6 Technical Descriptions
6-19
Chapter 6 Technical Descriptions
High and Low Pass Filters
1 FREQ Knobs
Set the turnover frequencies.
2 SLOPE Push-Buttons
Set dB/Octave 6-36dB in 6dB increments.
3 / LF Push-Button
Switches the high pass filter in/out.
4 HF \ Push-Button
Switches the low pass filter in/out.
Five Band Equaliser (LF, LMF, MF, HMF & HF)
5 +/- Knobs
Set the boost or cut levels.
6 FREQ Knobs
Set the centre frequencies or turnover frequencies for shelf curves.
7 Q Knobs
Set the bandwidth of EQ curves.
8 IN Push-Buttons
Allow individual EQ sections to be switched in/out.
9 & (LF & HF) Push-Buttons
Select shelving curves for high and low sections.
When LF or HF are in shelf mode, their ‘Q’ knobs control overshoot.
0 A & B Push-Buttons
Two complete EQ (but not Filter) settings may exist simultaneously. The
A and B buttons allow toggling between them for comparison purposes.
!¡ !¡ !¡ !¡ !¡ +/- Push-Buttons
Select the functions for the EQ definable knob and {IN} button.
!™ !™ !™ !™ !™ 8 Character Display
Displays the function type selected using the { + } / { - } buttons !¡
!¡ !¡ !¡ !¡.
!£ !£ !£ !£ !£ Definable Knob
Used to adjust or further select options set according to the { + } / { - }
buttons !¡
!¡ !¡ !¡ !¡.
!¢ !¢ !¢ !¢ !¢ IN Push-button
Switches in options set according to the { + } / { - } buttons !¡
!¡ !¡ !¡ !¡ and the EQ
definable knob.
