Chapter 6 Technical Descriptions
6-21
Chapter 6 Technical Descriptions
3 ACCESS Push-Button(s)
Allows Free Assign controls to access control of selected process.
Note:
Selecting any IN button selects its associated ACCESS automatically.
6 Definable Knobs and 6 Switches
4 8 Character Displays
Indicate the functions of adjacent definable knobs and switches.
5 DEFINABLE Knobs
Allow adjustment of parameter indicated.
6 Push-Buttons
Allow switched function as indicated.
7 Dynamics Meters
4 x 20 segment meters indicate gain reduction within the Dynamics section
for the GATE, EXPANDER, COMPRESSOR and LIMITER functions.
Back-lit legends above each meter indicate which particular Dynamics
sections are switched into the signal path.
The IN button below the window selected to DYN on the Input Channel &
Inserts section can be used as a master in/out switch for the whole
dynamics section.
Stereo Meter [Lower centre] (Not operational in this version)
The two meters between the two columns of IN buttons indicate audio
levels within the process currently accessed. A back-lit arrow will point to
the appropriate IN button. The Meter switch functions are as follows:
8 INPUT Push-Button
Switches the meter to read the input of the accessed process.
9 OUTPUT Push-Button
Switches the meter to the process output.
0 METERS HOLD Push-Button
Fixes the meter to the process accessed at the time. Once selected, the
meters will not follow further access functions until METERS HOLD is
released.
