Chapter 4 Signal Paths
4-51
Chapter 4 Signal Paths
HOLD button(s)
Clicking on and highlighting in red any of the HOLD buttons in the GUI
will cause the current monitor selection to be frozen, in that flipping
between SENDS and RETS will only affect those not ‘held’.
CUT button(s)
Cuts its stem signal.
SOLO button(s)
Solos its stem signal.
MASTER Row
SEND button
Selects the monitor source as the signal being sent to tape for all stems.
The button then alternates to RETURN in readiness for selecting the signal
returning from tape for all stems.
CUT button
Cuts all stem monitor signals.
HOLD CANCEL button
Cancels any HOLD buttons set on in the GUI.
The Softkeys for this GUI:
• TOP - Selects the top level LOGO screen
• FOLD 1 - Selects FOLD-DOWN MATRIX 7.1 b b b b b 5.1 b b b b b LCRS
• FOLD 2 - Selects FOLD-DOWN MATRIX 5.1 b b b b b STEREO b b b b b
MONO
