Chapter 6 Technical Descriptions
6-2 Channels Section Panels
This panel contains a Level control and an ON button for each Send and
allows control of the signals sent from the channel currently accessed. The
source point can be set individually for each Send.
1
Bus Access Push-Buttons
The + and - Push-buttons (large rectangular type) allow access to each bus
in turn in order to allow source point selection for each Send individually.
The 8 character display indicates the bus number or name.
SENDS 1-24 panel
6-2-10 Sends 1-24 Panel
