MotionSuite™ Series Machine Controller Software Manual Chapter 4: File Manager
4-26
4.1.16 Detail Display Window
The folder or file selected in the Tree-like Display Window is detailed in the Detail
Display Window. The contents shown in this window vary according to the folder or
file selected in the Tree-like Display Window. However, nothing is displayed if the
root folder is selected.
When the Group or Order (Customer) Folder is Selected
1. File Name
Group or Order (Customer) folder name is displayed.
2. File Type
Folder or file type is displayed.
When the PLC or CPU Folder is Selected
1. File Name
PLC or CPU folder name is displayed.
2. File Type
Folder type is displayed.
3. PLC Type
PLC type is displayed.
Titles of the Detail Display Window
1 2
Titles of the Detail Display Window
1 2
3
4
5
6
7
8
9
10
