On channels with the XDP (HD) license, for similar frame rates (25/50 fps or 29.97/59.95 fps), SD
material transferred or recorded into the K2 Summit/Solo system along with its audio is up-converted
when played on a HD output channel. Likewise, HD material is down-converted along with its audio
when played on an SD output channel. HD and SD clips can be played back-to-back on the same
timeline, and aspect ratio conversion is user configurable.
The K2 Summit/Solo system supports mixed clips with uncompressed and compressed (PCM, AC3,
and Dolby) audio on the same timeline.
25/50 fps conversions on HD K2 Summit/Solo system models
The following specifications apply to K2 Summit/Solo system channels with the XDP (HD) license.
Converted HD format Converted HD format Converted SD format
720p at 50 fps 1080i at 25 fps 625 at 25 fps
Up-convert
SD to HD
Up-convert
SD to HD
No conversion 625 at 25 fps Source SD
format
Cross-convert from
1080i to 720p No conversion Down-convert
HD to SD
1080i at 25
fps Source HD
format
No conversion Cross-convert from 720p to
1080i Down-convert
HD to SD
720p at 50
fps
29.97/59.95 fps conversions on HD K2 Summit/Solo system models
The following specifications apply to K2 Summit/Solo system channels with the XDP (HD) license.
Converted HD format Converted HD format Converted SD format
720p at 59.94 fps 1080i at 29.97 fps 525 at 29.97 fps
Up-convert
SD to HD
Up-convert
SD to HD
No conversion 525 at 29.97
fps Source SD
format
Cross-convert
HD to HD
No conversion Down-convert
HD to SD
1080i at
29.97 fps Source HD
format
No conversion Convert
HD to HD
Down-convert
HD to SD
720p at
59.94 fps
Aspect ratio conversions on HD K2 client
The following specifications apply to K2 Summit/Solo system channels with the XDP (HD) license.
