Specification Characteristic
To 10,000 feet
IEC 950 compliant to 2000 meters
Operating Altitude
To 40,000 feet Storage Altitude
30G 11 ms trapezoid Non-Operating Mechanical
Shock
0.27 GRMS (5-500Hz) Random Vibration
Operational
2.38 GRMS overall
.0175 g2/Hz (5-100Hz)
.009375 g2/Hz (200-350Hz)
.00657 g2/Hz (500 Hz)
Random Vibration
Non-Operational
Information Technology Equipment Type
Class 1 Equipment Class
Category II Local level mains, appliances, portable equipment, etc. Installation Category
Level 2 operating environment, indoor use only. Pollution Degree
Specifications vary for transmission products.
Mechanical specifications
The K2 Summit 3G Production Client specification is shown in the following table
Measurement Dimension
3.5 in (89mm) Height
17.6 in (447 mm) Width
24.3 in (617 mm) total 23.0 in (585 mm) rack depth Depth
1
55.0 lbs (25.0 kg) maximum Weight:
The first generation K2 Summit Production Client specification is shown in the following table
Measurement Dimension
3.5 in (89mm) Height
17.6 in (447 mm) Width
24.3 in (617 mm) total 23.0 in (585 mm) rack depth Depth
2
1
Adjustable rack-mounting ears accommodate different rack depth limitations.
2
Adjustable rack-mounting ears accommodate different rack depth limitations.
226 K2 AppCenter User Manual 29 October 2012
Specifications
