Page 176
5. Configure as follows:
Configure as needed...
For this setting...
Select
Yes
to create a data track and store ancillary data packets.
Record ancillary data
Select
Yes
to automatically convert CEA-608 closed caption data to
708 DTV CC packets.
CEA-608 to DTV CC
transcoder
Available if SD selected. Selecting No retains compatibility with Profile
XP Media Platform.
Record uncompressed
VBI and captioning to
data track
Available if SD selected.
Uncompressed VBI
lines
Click a link in this section to map one or more Teletext lines to play
out on a different line.
Teletext Output Lines
Map the video line which OP-47 ancillary data packets are output for
playout, or select
Source line
to leave the packets unmoved.
Output OP-47 packet on
line
Related Topics
Configuring video reference standard settings
on page 167
Data bridging of VBI information on K2 Summit/Solo HD channels
on page 245
Line mapping of ancillary data packets on K2 Summit/Solo HD channels
on page 246
on page 245
Configuring timecode settings
1. In AppCenter, click
System | Configuration
.
Configuration Manager opens.
2. Click
System
.
3. Configure as follows:
Configure as needed...
For this setting...
Select one of the following:
Time of Day
•
System Clock
: This settings uses the Windows operating system
clock. If you select this source you should verify that the clock’s
time is correct.
•
LTC Input
: Choose if using LTC timecode. Select which channel you
want to use as the Time of Day source.
176
K2 AppCenter User Manual
29 October 2012
Audio/Video Configuration
