3. Scroll to locate and configure settings as follows:
Configure as needed... For this setting...
If licensed for AppCenter Elite you can configure the channel to be a
ChannelFlex Suite Channel. When you do so, settings change
accordingly. Type
If desired, enter a name for the channel. Name
NTSC or PAL available depending on video reference standard setting. Video Output
Select a HD or SD format. Aspect ratio
Select the conversion option. Refer to topics about aspect ratio
conversions. Aspect ratio conversion
Determines how to generate the still-play signal for the play channel
when it is setup to freeze on last frame of video in stop mode. You can
select the following: Still-play mode
• Field (interpolated) : This is the default setting and uses the content
of one field for both fields during still-play for a one field freeze.
This mode eliminates the motion jitter that can be present in
Interlaced mode.
• Frame (interlaced) : This mode displays two fields in still play mode
for a two field freeze. With this mode you might see some motion
jitter in still-play.
Temporarily displays 75% colorbar signal on the channel output. It also
generates an audio tone on all audio outputs. This setting is for test
purposes only, so it is not saved. Test Mode (Colorbars +
Tone)
Delays the video output. Video Output Timing
If 720p or 1080i selected, inserts the recorded timecode track as ancillary
timecode on playout. Overrides any ancillary timecode packets stored
on data track. Refer to specifications about data track support. Ancillary data timecode
output
If SD is selected, you can select VITC lines. VITC output generator
