NOTE: Some video output connectors become inactive for some video type selections. For more
information on video output connectors, see "K2 System Guide".
Related Topics
Active Format Description (AFD) specifications on page 237
About aspect ratio conversion modes
The aspect ratio conversion mode setting for the play channel determines how the picture image is
resized for playout.
Related Topics
Aspect ratio conversions on HD K2 client on page 235
Applying AFD settings
Active Format Description (AFD) can be used to automatically determine the proper aspect ratio to
use for up- and down-conversions.
In AppCenter, you can specify the AFD settings:
• in the Clip Properties dialog box, for that clip only
• in the Channel Options dialog box, for newly recorded clips on that channel
You can also make settings in Configuration Manager to specify under what conditions the K2
Summit/Solo system should process AFD (for output only, on a per-channel basis).
When recording, the following AFD settings are available:
HD SD
Undefined ( Undefined means no AFD has been
set; the clip remains as is.) Undefined
4:3 Pillarbox 16:9 Full screen
16:9 Full screen 4:3 Full screen
14:9 Pillarbox 16:9 Letterbox
16:9 Full screen with 4:3 center 14:9 Letterbox
Channels with HD licenses need to set the AFD values when aspect ratio conversion has been
performed while playing out video. Channels that are SD-only do not perform aspect ratio conversion;
AFD values do not need to be adjusted on those channels.
Clips with AFD recorded on a K2 Media Client will play on a K2 Summit/Solo system, and vice
versa. Clips will have either ARC or AFD properties, not both. AFD in ancillary data is preserved
in the data track during recording.
