8 – Dynamics processors—DYNAMICS (master channels)
TASCAM DM-24 Reference Manual
65
DYNAMICS (master channels)
The screen accessed by the DYNAMICS key when a
master channel (an aux send, a buss or the stereo
master) is selected is slightly different from the
screen displayed when a channel 1–16 is selected:
The screen above shows two linked aux sends (1 and
2), but the same principle applies to buss masters as
well as the stereo master.
Note that the following features are different from
the channel 1–16 dynamics screens:
No expander or gate available for these mas-
ter screens. Any on-screen controls associated with
these processors are therefore unavailable. This
includes the soft keys—only the compressor library
is available from these screens.
Insert point The insert point is fixed to pre-fader.
Linking The way in which the links are labeled is
different for master modules. Instead of the channels
being referred to as left and right, they are referred to
as 1and 2 (“left” and “right” do not have any real
meaning in these cases).
Assigning processors to master channels
The assignment of stereo compressors to up to three
master channels is done using the
I/O display ASSIGN
SECT. sub-screen
Use the fourth soft key to bring up the master assign-
ment section.
Move the cursor to the second column ( MASTER
COMP INSERT MATRIX ), and use the dial to assign the
possible master channels (confirm with ENTER ).
NOTE
The stereo master counts as two channels, as shown in
the sample screen here.
