SNM-1010L Data/Control Modem Revision 0
Front Panel Operation MN/SNM1010L.OM
ODU 10 MHZ REF
OFF
Displays the ODU 10 MHz REF, either On or Off.
Upon entry, the current ODU to 10 MHz REF is displayed with the flashing cursor on the
first character. Press [
↑ ] or [↓ ] change the modem reference. Press to execute
the change.
3.4.1.1.13 CONFIGURATION:MODULATOR:RS ENCODER
RS ENCODER
OFF
Note: Reed-Solomon option only.
Displays the RS encoder status, either On or Off.
Notes:
1. Programming the Reed-Solomon encoder automatically turns off the RF
transmitter, because of symbol rate changes.
2. If none of the proper overhead types and data rates apply, the Reed-Solomon
encoder program in the On state will be rejected (double beep).
3.4.1.2 CONFIGURATION:DEMODULATOR
CONFIGURATION
DEMODULATOR
3–12
