Steering end point function, curve function, speed function, or D/R function setup also
HIIHFWVÀDSFKDQQHORSHUDWLRQ+RZHYHUHYHQLIVHWVWHHULQJUHYHUVHIXQFWLRQVHWXSGRHV
QRWUHYHUVHWKHÀDSFKDQQHO
Effect of the set value of other functions on tilt mixing
Tilt Mixing
(Preparation)
- Use the function select dial function to select the flap channel
operation dial. (p.101)
1
(Function ON/OFF)
Refer to the left page and turn on the function and set the
mixing channel (flap).
2
(Flap rate check and adjustment)
Select the setting item "Flap" by (JOG) button up or down
operation, and adjust the flaps by (+) or (-) operation.
3
(Rudder to Flap mixing amount adjustment)
Select setup item "Rudder to Flap" by (JOG) button up or
down operation, and use the (+) and (-) buttons to adjust the
mixing amount.
"+" :Operate in same direction as steering
"-" :Operate in opposite direction of steering
4
(Flap to Rudder mixing amount adjustment)
Select setup item "Flap to Rudder" by (JOG) button up or
down operation, and use the (+) and (-) buttons to adjust the
mixing amount.
"+" :Operate in same direction as channel 3
"-" :Operate in opposite direction of channel 3
Tilt mixing adjustment
The mixing rate amount can be controlled with digital dial or digital trim, using the
function select dial function. (p.101)
Dial / Trim Setting
Rudder to Flap channel side : +100%
Flap channel to Rudder side : -100%
Slave channel output (Initial value)
Setting buttons
- Use the (+) and (-) buttons to
make adjustments.
Function ON/OFF (Mode)
ON, OFF
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
- Return to the initial value by
pressing the (+) and (-) buttons
simultaneously (approx. 1 sec).
Flap rate
-100~+100
Initial value: 0
Mixing amount (Rudder to Flap)
-100~+100
Initial value: +100
Mixing amount (Rudder to Flap)
-100~+100
Initial value: +100
5
When ending setting, return to the Mixing menu screen by pressing the (END) button.
