HOME
screen
or
MENU 2 screen
Sensor menu screen Sensor list
Push
MENU 1
screen
sensor
The required number of
slots
The number which can be used as a start slot
TEMP(SBS-01T) 1 slot 1~31
RPM(SBS01RM) 1 slot 1~31
Voltage(SBS-01V)
2 slot
1 , 2 , 3 , 4 , 5 , 6 , 8 , 9 , 1 0 , 1 1 , 1 2 , 1 3 , 1 4 , 1 6 , 1 7 , 1 8 , 1 9 ,
2 0 , 2 1 , 2 2 , 2 4 , 2 5 , 2 6 , 2 7 , 2 8 , 2 9 , 3 0
Select by (JOG) button up,
down, left or right operation,
and use the (+) and (-) buttons
to make adjustments.(sec)
136
Fu
n
c
tio
n
6HUYRVDUHFODVVL¿HGE\&+EXWVHQVRUVDUHFODVVL¿HGLQXQLWVFDOOHGVORW7KHUHDUH
slots from No. 1 to No. 31. Using a sensor which uses two or more slots, the required
number of slots is automatically assigned by setting up a start slot. When 2 or more of
the same kind of sensor are used, the sensors themselves must allocate unused slots and
memorize that slot.
What is a slot?
Sensor Menu
The interval at which the voice guide of the telemetry information is read and the interval at
which the log data is recorded can be set at this screen.
Sensor List
The sensors registered at the T4PX are displayed. When sensor reloading, sensor registra-
tion, slot number change, etc. is performed, it is added to the list and the list is changed.
Sensor Menu
This menu registers the telemetry sensors used with the transmitter. When only one of a certain
type of sensor is used, this setting is unnecessary and the sensor can be used by simply connect-
ing it to the S.BUS2 port of the transmitter.
When using 2 or more of the same kind of sensor, they must be registered here.
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
- Return to the initial value by
pressing the (+) and (-) buttons
simultaneously (approx. 1 sec).
Interval
0 ~ 30sec
Initial value:0
Press
Press
Press
Press
