Futaba 4PX 2.4GHz FASST T-FHSS S-FHSS - Manual (Page 64)

Setting item
Mode
:Speed type selection
All :Speed adjustment
Setup item selection
- Select by (JOG) button up or down
operation.
Setting item
Mode
:Speed type selection
High :High side range speed
adjustment
Low :Low side range speed
adjustment
Point1 :Low and medium speed
switching point
Setup item selection
- Select by (JOG) button up or down
operation.
Throttle trigger position
Throttle trigger position
The Low and High ranges are
linked to the Point1 set point
and displayed.
Adjustment range
High :1~100
Low :1~100
At 100%, there is no delay.
Point1 :1~100
Adjustment buttons
- Adjust with the (+) and (-) but-
tons.
- Return to the initial value by
pressing the (+) and (-) buttons
simultaneously (approx. 1 sec).
Initial value
Low, High :"100"
Point1 :30
Speed type Select button
- Select with the (+) or (-) but-
tons.
Adjustment buttons
- Adjust with the (+) and (-) but-
tons.
- Return to the initial value "100"
by pressing the (+) and (-) but-
tons simultaneously for about 1
second.
Adjustment range
1~100% (each direction)
At 100%, there is no delay.
Speed type Select button
- Select with the (+) or (-) but-
tons.
64
Fu
n
c
tio
n
Throttle Speed
(Preparation)
- Select the setting item "Mode" by (JOG) button up or down op-
eration. Press the (+) or (-) button and select "1".
Adjustment method for 1 Speed
(Preparation)
- Select the setting item "Mode" by (JOG) button up or down op-
eration. Press the (+) or (-) button and select "2".
Adjustment method for 2 Speed
1
("Low" and "High" delay adjustment)
Select "Low" or High" by (JOG) button up or down operation.
Use the (+) or (-) button to adjust the delay of the entire
throttle forward side range.
2
(Speed switching point adjustment)
When you want to change the "Low" and "High" switching
point, select the setting "Point1" by (JOG) button up or down
operation.
3
When ending setting, return to the speed screen by pressing
the (END) button.
1
("ALL" delay adjustment)
Select "All" by (JOG) button up or down operation.
Use the (+) or (-) button to adjust the delay of the entire
throttle forward side range.
2
When ending setting, return to the speed screen by pressing
the (END) button.
