Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
- Return to the initial value by
pressing the (+) and (-) buttons
simultaneously (approx. 1 sec).
Drive ratio
Front 0%:Rear 100%
~ Front 100%:Rear 0%
Initial value:
Front 100%:Rear10 0%
Setting buttons
- Use the (+) and (-) buttons to
make adjustments.
MIX mode
OFF, ON
Initial value: OFF
Trim mode
OFF, ON
Initial value: OFF
91
Fu
n
c
tio
n
DUAL ESC Mixing
Use a 50:50 trigger ratio setting. (P66)
Trigger ratio Setting
(Preparation)
- This function has 2 methods. One method is used by switching the drive type (4WD/front/
rear) by one digital trim/dial. The other method performs switching by assigning a switch to
each mode (4WD/front/rear). Both methods are set from among DL1 and DT~1DT6 by dial
select function. (P101)
Dual ESC mixing adjustment
2
(Drive ratio adjustment)
Adjust the front and rear motor controller operation amount
by (+) or (-) button.
The (+) button increases and the (-) button decreases the
rear ratio.
Both the front and rear ratios become 100%
3
(Mix mode setting)
Operate the (JOG) button up and down and select the setting
item "MIX mode". Set the mix mode with the (+) or (-) button.
"OFF" :The EXP function of the 2nd CH and other settings are not mixed.
"ON"
:The EXP function of the 2nd CH and other settings are mixed.
4
(Trim mode setup)
Select setup item "Trim mode" by (JOG) button up, down,
left, or right operation, and use the (+) or (-) button to select
the mixing mode.
"OFF" :Trim of the 2nd CH is added.
"ON" :Trim of the 2nd CH is removed.
The function select dial function can control the drive ratio with digital dial or digital
trim, using the function select dial function. (p.101)
Dial / Trim Setting
As this function drives 2 separate motor controllers simultaneously, a mutual load is ap-
plied. Use this function carefully so that the motor controllers are not damaged.
Futaba will not be responsible for motor controller, motor, and other vehicle trouble due
to use of this function.
Note:
1
(Dual ESC setting)
Refer to the left page and set the function to ON and set the
mixing channel.
When switching by one digital trim is set, the set switch per-
forms switching as shown below.
Front drive 4WD Rear drive
5
When ending setting, return to the Mixing menu screen by pressing the (END) button.
