Mixing menu screen
Press
Press
Press
Press
88
Fu
n
c
tio
n
This function is a remote gain function which adjusts the sensitivity of the Futaba car rate
gyro at the T4PX side, and is mixing that uses the 3rd or 4th CH to adjust the gyro sensitiv-
ity. When using the T4PX by switching the AVCS and normal modes use PS1- PS5 with the
function select switch function (p.99).
For a description of the car rate gyro mounting method and handling, refer to the rate gyro
instruction manual.
Gyro Mixing (Steering system)
Gyro Mixing
AVCS / NORMAL Modes
The gyro has 2 operating modes: NORMAL mode and AVCS mode. In the AVCS mode, the angle is
controlled simultaneously with NORMAL mode rate control (swing speed). The AVCS mode increas-
es straight running stability more than that of the NORMAL mode. Because the feel of operation is
different, choose your favorite mode.
NORMAL
Countersteers against outside
force, but cannot correct the
skid direction.
AVCS
Corrects the skidding direc-
tion and forcefully maintains
the heading.
Outside
force
Outside
force
The mixing function is assigned to CH3 and CH4. Channels used by other mixing can-
QRWEHXVHG:KHQWKHQXPEHURIFKDQQHOVLVLQVXI¿FLHQWFDQFHOWKHRWKHUPL[LQJ
The mixing used can be confirmed on
the Auxility screen. (p.155)
Gyro mixing screen from mixing menu screen (p.79)
When channels 3 and 4
are used by other mix-
ing, the message "No
assignable channel" is
displayed.
Channel is selected by
(JOG) button operation.
When Gyro mixing is set to
"ON", the gain steering chan-
nel setup screen is displayed.
