Futaba 4PX 2.4GHz FASST T-FHSS S-FHSS - Manual (Page 155)

HOME
screen
MENU 1
screen
or
MENU 2 screen
When mixing set at auxiliary channel
Press
155
Fu
n
c
tio
n
Auxiliary Channel "CH3","CH4"
Auxiliary Channel "CH3","CH4"
The channel 3/4 servo position can be set from the transmitter. When CH3 is assigned to a
dial by the dial function (p.101), this setting is linked to that dial.
When CH3/4 is not assigned to a dial, it can be set with this screen.
When CH3/4 is assigned to a switch by the switch function (p.99), you cannot adjust the
CH3/4 via the screen.
:KHQ&+RU&+LVDVVLJQHGE\PL[LQJIXQFWLRQFKDQQHORSHUDWLRQFDQQRWEHSHUIRUPHG
at this screen.
Setup Item
Channel 3 position
Channel 4 position
Channel 3: Dual ESC mixing
Channel 4: Steering mixing
1
(Position adjustment)
Use the (+) and (-) buttons to adjust the channel 3 or chan-
nel 4 position.
2
When ending setting, return to the initial screen by pressing
the (END) button twice (for function menu screen, press the
(END) button once).
Channel 3/4 adjustment
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
- Press the (+) and (-) buttons
simultaneously (approx. 1 sec)
to return to the initial screen
Channel 3 position (POSI)
Channel 4 position (POSI)
0~100%
Initial value: 100%
Press
Press
Pre Press
