Setup item
Battery type
Alarm voltage
Vibrator
Auto powar off
Setup item selection
- Select by (JOG) button up, or
down operation.
-Setup buttons
- Use the (+) and (-) buttons to
make setup.
148
Fu
n
c
tio
n
System menu
Battery setting
This setting is displayed from the screen of the system menu. (p.144)
Battery Type Setting
With the T4PX, the low battery alarm setting is different, depending on the type of battery.
Therefore, always set the battery type matched to the power supply to be used. When using
D)XWDEDUHFKDUJHDEOHW\SHEDWWHU\DOZD\VVHOHFW/L)HFHOOVRU1L0+FHOOV". Incorrect
setting will substantially shorten the time from low battery alarm to system stopping and is
very dangerous.
([FHSWLRQDOO\ZKHQXVLQJDEDWWHU\RWKHUWKDQWKLVVHOHFW"Other" and set the low battery
alarm voltage on your own responsibility. Futaba is not responsible for trouble caused by
XVHRIDQXQVSHFL¿HGEDWWHU\
1
(Select battery type)
Select the "Battery type" to be set by (JOG) button operation,
and use the (+) and (-) buttons to select the attery type.
2
(Setting low bwttery alarm voltage)
When a specified battery was set by battery type, the alarm
voltage is automatically set and cannot be adjusted. When
"Other" was set by battery type, set the alarm voltage your-
self. Select the "Alarm voltage" to be set by (JOG) button op-
eration, and use the (+) and (-) to adjust the volutage.
3
(Select vibrator type)
Select the "Vibrator" to be set by (JOG) button operation, and
use the (+) and (-) buttons to select the Vibrator type.
Select the vibrator type from among Inhibit, Continuous,
Slow, and Fast. When vibration is not linked with the battery
alarm, select "Inhibit".
4
(Auto power off sertting )
Select the "Auto power of" to be set by (JOG) button opera-
tion. Set the function to the active state by pressing the (+) or
(-) button.
Battery setting
Battery type
LiFe 2cells, NiMH 5cells, Other
Alarm voltagre (Other battery)
4.2V~8.0V
Initial value: 4.2V
Vibrator tyape
Inhibit, Continuous, Slow, Fast
Auto power off
ON, OFF
5
When ending setting, return to the system menu screen by pressing the (END) button.
