DeviceMaster UP Modbus/TCP User Guide: 2000447 Rev. I Chapter 2. Programming Interface - 57
Requirements
2.4.1. Requirements
Your PLC-5/SLC must support:
• MultipHop
• ControlLogix devices
• EtherNet/IP
The following tables list PLCs that support EtherNet/IP and the required firmware version for each PLC.
Note: Older versions of the PLC firmware may or may not provide EtherNet/IP functionality. You must verify
that an older version of the PLC firmware provides EtherNet/IP functionality before you can use it with
DeviceMaster UP. If you need to update your PLC firmware, contact your Rockwell distributor.
2.4.1.1. SLC 5/05
2.4.1.2. PLC-5
Models Catalog Numbers Required Firmware Version for EtherNet/IP
SLC 5/05
1747-L551
1747-L552, 1747-L553
Series A: FRN 5 or later
Series C: FRN 3 or later
Reference: SLC 500 Instruction Set, Appendix A Firmware History, Rockwell Publication 1747-RM001D-
EN-P
Models Catalog Numbers Required Firmware Version for EtherNet/IP
Ethernet PLC-5
1785-L20E, 1785-L40E,
1785-L80E
Base EtherNet/IP functionality:
Series C: Revision N or later
Series D: Revision E or later
Series E: Revision D or later
Full EtherNet/IP Compliance:
Series C: Revision R or later
Series D: Revision H or later
Series E: Revision G or later
Enhanced PLC-5
attached to
Ethernet Module
1785-L11B, 1785-L20B
1785-L30B, 1785-L40B
1785-L40L, 1785-L60B
1785-L60L, 1785-L80B
Series B: Revision N.1 or later
Series C: Revision N or later
Series D: Revision E or later
Series E: Revision D or later
ControlNet PLC-5
attached to
Ethernet Module
1785-L30C15
1785-L40C15
1785-L60C15
1785-L80C15
Series C: Revision N or later
Series D: Revision E or later
Series E: Revision D or later
All revisions
Ethernet Module 1785-Enet
Series B:
Base EtherNet/IP functionality: All revisions
Full EtherNet/IP Compliance: Revision D or later
References:
• Enhanced & Ethernet PLC-5 Series and Enhancement History, Rockwell Publication G19099
• ControlNet Processor Phase, Series and Enhancement History, Rockwell Publication G19102
• PLC-5 Programmable Controllers System Selection Guide, Rockwell Publication 1785-SG001A-EN-P - March 2004
• Ethernet Interface Module Series B, Revision D Product Release Notes, Rockwell Publication 1785-RN191E-EN-P -
December 2002
