Instance Attribute Definitions
Attribute 8
Device Connection
Socket Port
This is the device socket port number the DeviceMaster UP connects to if the Device
Connect Mode is set to either Connect Always or Connect On Data.
Attribute 9
Device Connection IP
Address
This is the device IP address the DeviceMaster UP connects to if the Device Connect
Mode is set to either Connect Always or Connect On Data. The IP address is in
hexadecimal format. For example, an IP address of 10.1.2.100 is 0A010264 in
hexadecimal.
Attribute 10
Device Idle Timeout
The idle timeout period in milliseconds that is used if the Device Disconnect Mode is
set to Disconnect On Idle.
Attribute 11
Receive Timeout
Between Packets
This attributes specifies:
• How long DeviceMaster UP waits (in milliseconds) if the Receive ETX length is
not zero (0) and it does not receive an ETX byte sequence.
• The time to wait (in milliseconds) between Ethernet packets if the Receive ETX
Detect length is set to zero (0).
Attribute 12
PLC IP Address
This attribute specifies the IP address in hexadecimal format for the PLC EtherNet/
IP card. For example, an IP address of 10.1.2.100 is 0A010264 in hexadecimal.
Note: The Polling method does not use this attribute.
Attribute 13
Receive (DeviceMaster
UP to PLC) Ethernet
Data Transfer Method
This attribute specifies Ethernet data transfer method used by the DeviceMaster
UP for the specified socket port. Refer to Attribute 17 of the Serial Port
Configuration Object for a detailed explanation of these methods.
Attribute 14
PLC Controller Slot
Number
This attribute specifies the slot number on the PLC where the controller resides.
The slot numbers typically start at zero (0) for the first slot.
Note: This is generally zero for CompactLogix PLCs. The Polling method does not
use this attribute.
Attribute 15
Socket Port Data
Transfer Options
This attribute specifies the socket port transfer options. The following options are
supported:
• 01 Hexadecimal (Bit 0) = (PLC-5/SLC only) Receive Most Significant (MS) byte of
16 bit integer first. The default is transmit least significant (LS) byte first.
• 02 Hexadecimal (Bit 1) = (PLC-5/SLC only) Transmit Most Significant (MS) byte
of 16 bit integer first. The default is transmit least significant (LS) byte first.
• 04 Hexadecimal (Bit 2) = Tx Sequence Number Checking
- DeviceMaster UP rejects messages with duplicate sequence numbers, (that
is, the same sequence number as the previous transmit data message), and
increments the Duplicate Transmit Sequence Error Count.
- DeviceMaster UP transmits messages with unexpected transmit sequence
numbers, (that is, sequence numbers that are not the same as or are not
equal to the previous sequence number plus one) increments the
Unexpected Transmit Sequence Error Count.
• 08 Hexadecimal (Bit 3) = Disable Queuing of Non-Filtered Rx Messages to the
PLC. If filtering is disabled, only the last message received is sent to the PLC.
• 10 Hexadecimal (Bit 4) = Drop oversized received data packets.
Attribute 16
Maximum PLC Update
Rate
The maximum rate (or minimum time interval) in milliseconds, that messages are
sent to the PLC tag in the Write-To-Tag receive method. This attribute configures
the DeviceMaster UP to space the messages to the PLC to prevent overrunning of
data before the PLC can process it.
Attribute 17
Maximum Receive
Data Packet Size
Specifies the maximum acceptable size of a received Ethernet packet. The
maximum received Ethernet packet size is 2048 bytes while operating in Write-to-
Tag/File or Write-to-Tag-File-Synced receive modes.
Attribute Description (Continued)
