DeviceMaster UP Modbus/TCP User Guide: 2000447 Rev. I Chapter 2. Programming Interface - 35
Instance Attributes
15
Socket Port Transfer
Options
WORD
(bitwise
OR)
01 Hex = (PLC/SLC) Rx MS Byte First
02 Hex = (PLC/SLC) Tx MS Byte First
04 Hex = Tx Sequence Number Checking
08 Hex = Disable Queuing of Non-Filtered
Rx Messages
10 Hex = Drop oversized received packets
Set/Get
16
(Default=40)
Maximum PLC Update
Rate (No more than one
message per time period.)
UINT
(msec)
10-65535
(Default = 40)
Set/Get
17
Maximum Receive Data
Packet Size
UINT
1-2048
(Default = 440)
Set/Get
18
Received (DeviceMaster
UP to PLC) Produced
Data Tag Name STRING
(Array of
40 SINTS) ASCII String
19
Application Socket
Enable
USINT
0=Disabled
1=Enabled
Set/Get
20 Application Listen Enable USINT
0=Disabled
1=Enabled
Set/Get
21
Application Connect
Mode
USINT
0=Never
1=Connect Always
2=Connect On Data
Set/Get
22
Application Disconnect
Mode
USINT
0=Never
1=Disconnect On Idle
Set/Get
23
Application Listen Socket
Port
UINT 0-65535 Set/Get
24
Application Connect
Socket Port
UINT 0-65535 Set/Get
25
Application Connect IP
Address
UDINT
00000000 Hex to FFFFFFFF Hex
(Mask=255.255.255.255)
Set/Get
26 Application Idle Timeout
UDINT
(msec)
0 to FFFFFFFF Hex Set/Get
27 To PLC Filter Mode USINT
0=Off
1=String (128 byte maximum)
2=RFID (EPC Global formats)
3= Barcode (UPC/EAN formats)
Set/Get
28
To Application Filter
Mode
USINT
0=Off
1=String (128 byte maximum)
2=RFID (EPC Global formats)
3= Barcode (UPC/EAN formats)
Set/Get
Attribute
ID
Name
Data
Type
Data Value(s)
Access
Rule
