DeviceMaster UP Modbus/TCP User Guide: 2000447 Rev. I
Chapter 2. Programming Interface - 45
Instance Attribute Definitions
Attribute 35
Barcode Formats
This attribute defines barcode format to be used for both standard and eight digit
UPC labels. The term standard refers to UPC-A, EAN-13, JAN, and EAN-14
barcodes which all have ten company/product digits.
The standard and eight digit formats are selected independently and each operates
independently. It is important to note that the barcode filtering/data extraction does
not function if no format is selected.
Format
Numbering
Company
Product
Check
Digits
Digits
Digits
Digit
Standard Formats
None
N/A
N/A
N/A
N/A
Company-5/ Product-5
1-3
5
5
1
Company-6/ Product-4
1-3
6
4
1
Company-7/ Product-3
1-3
7
3
1
Company-8/ Product-2
1-3
8
2
1
Company-9/ Product-1
1-3
9
1
1
Eight Digit Formats
EAN-8 Number-2/Product 5
2
0
5
1
EAN-8 Number-3/Product 4
3
0
4
1
UPC-E
See the
DeviceMaster UP Filtering and Data Extraction Reference Guide
for further details.
Attribute 36
PLC Transmit STX
Append Value
You can set this attribute to append an STX (start of transmission) byte sequence
which is configurable as 1 or 2-bytes to the beginning of the Ethernet packet before
it is sent. The length indicates the number of STX bytes. The valid values for length
are:
•
0 (zero) - Setting this attribute to zero disables this function.
•
1 (one STX byte) - Inserts one STX byte before the data.
•
2 (two STX bytes) - Inserts two STX bytes before the data.
•
Value1 - Specifies the transmit character associated with the first STX byte.
(Only if the length is not zero.) You can specify a value between 0 and 255.
•
Value2 - Specifies the transmit character associated with the second STX byte.
(Only if length is two bytes.) You can specify a value between 0 and 255.
Attribute 37
PLC Transmit ETX
Append Value
You can set this attribute to append an ETX (end of transmission) byte sequence
which is configurable as 1 or 2-bytes to the end of the Ethernet packet before it is
sent. The length indicates the number of ETX bytes.
The valid values for length are:
•
0 (zero) - Setting this attribute to zero disables this function.
•
1 (one ETX byte) - Inserts one ETX byte at the end of the data.
•
2 (two ETX bytes) - Inserts two ETX bytes at the end of the data.
•
Value - Specifies the transmit character associated with the first ETX byte.
(Only if the length is not zero.) You can specify a value between 0 and 255.
•
Value2 - Specifies the transmit character associated with the second ETX byte.
(Only if length is 2-bytes.) You can specify a value between 0 and 255.
