Comtrol MC5001 - Manual

DIP Switch Setting
LED Functions
RS-232
RS-485/2 wires
RS-485/4 wires
RS-422/4 wires (Default)
NO
Function DIP Switch 2
OFF
ON
OFF
OFF (Default)
DIP Switch 1
ON
OFF
OFF
OFF (Default)
Note: After adjusting the DIP-switch, reboot the unit to activate the new settings.
Point to Point /Serial Ring
120 Ohm Terminator (TX)
120 Ohm Terminator (RX)
Function Switch position
Off (PTP)/On (SFR ), Default off (PTP)
Off (Disable)/On (Enable), Default off
Off (Disable)/On (Enable), Default off
DIP Switch
Switch 5
Switch 4
Switch 3
RX
TX
PWR
LED Function
Lit when the MC5001 is properly powered up and the status of the unit is OK.
Lit when transmitting data.
Lit when receiving data.
Lit when operating in SFR mode. Ring
2 0 0 0 5 0 4 R e v. B w w w. c o m t r o l . c o m
Quick Installation Guide
Comtrol Customer Service
Contact Method Web Address or Phone Number
Support http://www.comtrol.com/pub/en/support
Downloads ftp://ftp.comtrol.com/html/default.htm
Web Site http://www.comtrol.com
Phone 763.957.6000
