DeviceMaster UP EtherNet/IP User Guide: 2000424 Rev. L

Chapter 5. Programming the PLC - 143

PLC-5 PLC Programming Example Instructions

5.5. PLC-5 PLC Programming Example Instructions

This topic describes how to use RSLogix 5 to configure and run the DeviceMaster UP in a PLC-5 PLC
environment.

You can configure the RSLogix 5 PLC program examples to your site’s requirements. This program is included
in the self-installing file (.MSI) and is copied to the Comtrol/EtherNetIP directory on your computer when you
open the .MSI file and follow the prompts. The self-installing file includes the following RSLogix 5 PLC
program examples:

5.5.4. lpbkExampleSlcMsgPollRS5

5.5.5. lpbkExamplePlc5MsgPollRS5

These program examples are intended to aid the PLC programmer. These program examples were developed
with:

RSLogix 5 (version 6.00.00)

Enhanced PLC-5/20 (series E with revision J firmware)

Ethernet sidecar (version Enet/B)

Note: The PLC program examples are designed to interface with a DeviceMaster UP 1-port or on Port 1 of a 2-

port or 4-port. Additional programming is required to use all ports on a 2-port or 4-port.

Disclaimer: Comtrol supplies example PLC programs for demonstration purposes only.
They are intended for the sole purpose of an example loop-back demonstration in a
controlled lab environment. They are not intended for use in a production environment
and may not function correctly on all PLCs. Comtrol does not warrant these example
programs or any part thereof. The user assumes all liability for any modification to and
use of a modified example program.

5.5.1. What is RSLogix 5?

RSLogix 5 is a Windows ladder logic programming package for the PLC-5 PLCs.

Note: See the RSLogix 5 Help for more information on this product.

5.5.2. Requirements

The EtherNet/IP firmware must be installed on the DeviceMaster UP and configured as described in the

DeviceMaster UP Hardware Installation and Configuration Guide

.

The DeviceMaster UP must be installed on the same Ethernet network segment as the PLC.

RSLogix 5 must be installed on your computer. Note that the instructions in this guide require that you
have some familiarity with this programming application.

A loopback plug is required for the first port on the DeviceMaster UP when running an example PLC
program. See the

DeviceMaster UP Hardware Installation and Configuration Guide

for information on

loopback plugs.

The PLC program examples (.PC5, .SY5 and .SY6 files) are optional. You can copy the PLC program
examples from the CD or download the latest program examples from the Internet. See

1.4. Locating the

Latest Software and Documents

on Page 10, for the location of the PLC program examples.

Caution
