146 -

Chapter 5. Programming the PLC

DeviceMaster UP EtherNet/IP User Guide: 2000424 Rev. L

Configure the DeviceMaster UP for the RSLogix 5 Program

6.

Set the serial port settings under EtherNet/IP Settings to the following values.

7.

Click Submit.

Field

Settings

TX Sequence Number
Checking.

Select

Rx (To PLC) Ethernet
Transfer Method

Set to Polling for lpbkExampleSlcMsgPollRS5 and
lpbkExamplePlc5MsgPollRS5.

Set to Write-to-Tag/File for lpbkExamplePlc5MsgFileRS5.

Set to Write-to-Tag/File-Synced for lpbkExamplePlc5MsgFileSyncRS5.

PLC IP Address

Leave blank for Polling.

Set to IP Address of PLC for Write-to-Tag/File and Write-to-Tag/File-
Synced.

PLC Controller Slot Number Unused and can remain blank.

Rx (To PLC) Produced Data
Tag/File Name

Leave blank for Polling.

Set to $N10:0, the PLC receive filename for Write-to-File and Write-to-
File-Synced.

Reset Port

Select

Save in Flash

Select
