DeviceMaster UP Modbus/TCP User Guide: 2000447 Rev. I

Chapter 2. Programming Interface - 37

Instance Attributes

35

Barcode Formats

(Barcode Filtering Only)

UINT

Standard 12-14 Digit Format

(mask = 000F Hex)

00 Hex=NONE

01 Hex=Five Company/Five Product Digits

02 Hex=Six Company/Four Product Digits

03 Hex=Seven Company/Three Product

Digits

04 Hex=Eight Company/Two Product Digits

05 Hex=Nine Company/One Product Digits

Eight Digit Format

(mask = 00F0 Hex)

00 Hex=NONE

10 Hex=EAN-8; Two Company/Five

Product Digits

20 Hex=EAN-8; Three Company/Four

Product Digits

30 Hex=UPC-E

Set/Get

36

(Default=0

No STX)

As defined for Get/Set All

PLC Transmit STX Append Value

Structure of:

Value1 (Only valid if

Length not zero)

Value2 (Only valid if

Length=2)

As defined for Get/Set

Single

PLC Transmit STX

Append Value

Structure of:

Length

Value1 (Only valid if

Length not zero)

Value2 (Only valid if

Length=2)

USINT

USINT

USINT

USINT

USINT

0 to 255

0 to 25

0,1,2 (0=No STX) (Default=0)

0 to 255

0 to 255

Set/Get

Attribute

ID

Name

Data

Type

Data Value(s)

Access

Rule
