DeviceMaster UP EtherNet/IP User Guide: 2000424 Rev. L

Chapter 5. Programming the PLC - 161

EDS Files

5.6. EDS Files

You do not need to add DeviceMaster UP to RSLinx for normal DeviceMaster UP-to-PLC communications.
However, you can easily add the DeviceMaster UP and its associated Electronic Data Sheet (EDS) files to
RSLinx.

5.6.1. Requirements

EDS files and the associated icons are included in the self-installing file (.MSI) and are copied to the Comtrol/
EtherNetIP
directory on your computer when you open the .MSI file and follow the prompts.

The files named DeviceMaster UP_*.ico are icon files and files named DeviceMaster UP_dd_NNNN-x.xx.eds are
ODVA electronic data sheet files where dd is the model name, NNNN is the product ID number, and x.xx is the
version number.

File Name

Description

DeviceMaster UP_1P_9012-x.xx.eds†

DeviceMaster UP 1-port

DeviceMaster UP_1P_9013-x.xx.eds†

DeviceMaster UP embedded 1-port

DeviceMaster UP_4P_8763-x.xx.eds†

DeviceMaster UP 4-port

DeviceMaster UP_1P-x.xx.ico†

DeviceMaster UP 1-port icon

DeviceMaster UP_2P1E-x.xx.ico†

DeviceMaster UP 1-port icon

DeviceMaster UP_2P2E-x.xx.ico†

DeviceMaster UP 1-port icon

DeviceMaster UP_4P-x.xx.ico†

DeviceMaster UP 4-port icon

DeviceMaster UP_1P_9440-x.xx.eds

DeviceMaster UP 1-port (RoHS compliant)

DeviceMaster UP_1P_9441-x.xx.eds

DeviceMaster UP 1-port (RoHS compliant)

DeviceMaster UP_1P_9470-x.xx.eds

DeviceMaster UP embedded 1-port (RoHS compliant)

DeviceMaster UP_1P_9471-x.xx.eds

DeviceMaster UP embedded 1-port (RoHS compliant)

DeviceMaster UP_2P_9480-x.xx.eds

DeviceMaster UP 2-port with serial terminals and 1 Ethernet
port

DeviceMaster UP_2P_94811-x.xx.eds

DeviceMaster UP 2-port with serial terminals and 2 Ethernet
ports

DeviceMaster UP_2P_9550-x.xx.eds

DeviceMaster UP 2-port DB9 with 1 Ethernet port

DeviceMaster UP_2P_9560-x.xx.eds

DeviceMaster UP 2-port DB9 with 2 Ethernet ports

DeviceMaster UP_4P_9445-x.xx.eds

DeviceMaster UP 4-port (RoHS compliant)

DeviceMaster UP_4P_9447-x.xx.eds

DeviceMaster UP 4-port (RoHS compliant)

DeviceMaster UP_1P_9500-x.xx.eds‡

DeviceMaster UP 1-port (RoHS compliant) with EtherNet/IP
loaded at the factory

DeviceMaster UP_1P_9510-x.xx.eds‡

DeviceMaster UP embedded 1-port (RoHS compliant) with
EtherNet/IP loaded at the factory

DeviceMaster UP_4P_9520-x.xx.eds‡

DeviceMaster UP 4-port (RoHS compliant) with EtherNet/IP
loaded at the factory

† Where 9012, 9013 and 8763 indicates the model type for DeviceMaster UP and x.xx indicates the major

version associated with the file.

‡ Models that have EtherNet/IP loaded at the factory are identified with an EtherNet/IP label on the

DeviceMaster UP.
