DeviceMaster UP EtherNet/IP User Guide: 2000424 Rev. L

Chapter 5. Programming the PLC - 163

Troubleshooting RSLinx

5.6.4. Troubleshooting RSLinx

If RSLinx does not display the device after adding DeviceMaster UP and the EDS files to RSLinx, perform the
following procedure:

1.

Select File > Exit and Shutdown to exit and shutdown RSLinx.

2.

Remove the following files from your hard drive:

\Program Files\Rockwell Software\RSCOMMON\Harmony.hrc

\Program Files\Rockwell Software\RSCOMMON\Harmony.rsh

3.

Restart RSLinx. The DeviceMaster UP unit or units should now appear with the associated icon or icons.
