36 - Chapter 2. Programming Interface DeviceMaster UP Modbus/TCP User Guide: 2000447 Rev. I
Instance Attributes
29
Discard Unrecognized
Data Mode
(RFID and Barcode Filter
mode only)
USINT
0=Off
1=To PLC
2=To application
3=To PLC/application
Set/Get
30 RFID Antenna Grouping USINT
0=None
1=Groups of Twos
2=Groups of Threes
3=Groups of Fours
4=First Two Only
5=First Three Only
Set/Get
31 To PLC Filter Options
WORD
(Bitwise
OR)
01 Hex = Encoding Scheme
02 Hex = Filter Code
04 Hex = Antenna Number
08 Hex = Company Code
10 Hex = Product/Location Code
20 Hex = Serial Number
Set/Get
32
To Application Filter
Options
WORD
(Bitwise
OR)
01 Hex = Encoding Scheme
02 Hex = Filter Code
04 Hex = Antenna Number
08 Hex = Company Code
10 Hex = Product/Location Code
20 Hex = Serial Number
Set/Get
33 Filter Age Time
UDINT
(msec)
0 - FFFFFFFF Hex Set/Get
34
RFID Reader Interface
Type
UINT
0=Unspecified
10=Alien (Text Mode)
11=Alien (Terse Mode)
20=Intermec (Hex ASCII Mode)
Set/Get
Attribute
ID
Name
Data
Type
Data Value(s)
Access
Rule
