Chapter 6: HSIM-W6 Configuration with QuickSET
76
HSIM-W6 User’s Guide
The line configuration information shown in
must be supplied by your service provider.
The HSIM-W6 factory default settings are in bold.
The following definitions explain the fields in the Wide Area Synchronous configuration window.
Sync Port Type —
Displays the Synchronous port electrical interface type. The selections for
this field are V.35, RS422, RS232, and X.21. The default setting for this field is V.35. Table 5
explains the options for the Sync Port Type.
NOTE
The service provider (i.e., AT&T, Sprint, MCI, etc.) determines the settings for the
following fields. Consult the service provider for the correct settings.
Table 15 Telco Configuration Information
Configuration Information
Required by User
Configuration Information
Supplied by Service Provider
Sync Port Type
V.35, RS422, RS232 or X.21
Sync Clock Speed
64000
Sync Flow Control
Force CTS True or Force DSR True
Table 16 Sync Port Types
Sync Port Type
Interface
Type
Cable Type
Cabletron
Part Number
RS422
RS449
RS449
9380120
RS232
RS232
RS232
9380122
V.35
V.35
V.35
9380121
X.21
X.21
X.21
9380123
RS422
RS530
RS530
9380124
RS422
RS530A
RS530A
9380126
RS422
RS530 Alt A
RS530 Alt A
9380125
RS422
RS530A Alt A
RS530A Alt A
9380127
