Chapter A: WPIM Cable Specifications
HSIM-W6 User’s Guide 221
Table 53 provides WPIM-E1 DTE interface cable pin assignments.
Table 54 provides WPIM-E1 RJ45 network interface cable pin assignments.
Table 53 DTE Interface
Pin Signal
1 Receive Ring
2 Receive Tip
3 Shield Ground
4 Transmit Ring
5 Transmit Tip
6 Shield Ground
7 Not Used
8 Not Used
Table 54 Network Interface
Pin Signal
1 Receive Ring
2 Receive Tip
3 Not Used
4 Transmit Ring
5 Transmit Tip
6 Not Used
7 Not Used
8 Not Used
