Chapter 7: General Configuration Using Local Management
144 HSIM-W6 User’s Guide
IP General Config Screen
The IP General Config screen allows you to configure the HSIM-W6 for IP routing.
Access the IP General Config screen by using the arrow keys to highlight the IP General Config
option and then pressing ENTER. The IP General Config screen shown in
Figure 61 displays.
Figure 61 IP General Config Screen
IP General Configuration Status Fields
The following list describes each of the IP General Configuration status fields. The status fields are
for informational purposes only and cannot be modified.
Router Name — Displays the type of routing used.
Status — Displays the status of IP Routing.
UpTime — Displays the amount of time elapsed since the last time the HSIM-W6 was rebooted.
Version — Displays the IP Routing version number used on the HSIM-W6.
IP General Config
Router Name: IP
IP Routing: ENABLED
Redirector: FORWARD
UpTime: 0 days 0 hours 39 min
SAVE RETURN
2012_11
Version: XX.XX.XX
Status: Enabled
AdminStatusTime: 0 days 0 hours 39 min
System Level Setup
Server: 0.0.0.0
UDP Port: 37
37 of 999
UDP Type:
time
Port Level Setup
Port: 1
MAC Address: 00-00-1D-22-46-B0
Oper Status: Enabled Description: Ctron HSIM-W6 EnetPort
Interf. Type: ethernet-csmacd
Framing: Ethernet MTU: 1500
IP Routing: ENABLED IP Forwarding: ENABLED Proxy ARP: DISABLED
+PORT- +REDIRECTOR-
Address: 134.141.17.177 Mask: 255.255.0.0 Address Type: Primary
Network Bcast: Ones
