Chapter 7: General Configuration Using Local Management
164 HSIM-W6 User’s Guide
WAN Setup
The WAN Setup menu item accesses two screens which allow you to configure the HSIM-W6 for
a WAN Physical Interface Module (WPIM).
Access the WAN Physical Configuration screen, shown in Figure 68 , by using the arrow keys to
highlight the WAN SETUP menu item and pressing ENTER. The WAN Physical Configuration
screen displays.
Figure 68 WAN Physical Configuration Screen
NOTE
This section describes the HDSL WPIM. For all other WPIMs, refer to your specific
WPIM(s) Local Management Guide for information on this screen
.
WAN PHYSICAL CONFIGURATION
RETURN
Local Management Flash Image Version XX.XX.XX
SAVE [WPIM 1] WAN INT CONFIG
WPIM 1
Type: HDSL
BRIM #: 1
Mode: [Primary]
Active: Yes
Ifaces: 003-026
WPIM 1 Line Configuration
HDSL Tx Clock Source: [Loop-Timing]
HDSL Timeslot Configuration: [Fractional]
WPIM 2
Type: T1
BRIM #: 2
Mode: [Primary]
Active: Yes
Ifaces: 027
